Gurjan Plywood

Check the product detalis

Gurjan Plywood

Gurjan core and panels lend natural strength to plywood. Imported from South-East Asian countries, Gurjan is a fully mature, high density hardwood, which makes it naturally strong & resistant to all kinds of organisms. These veneers when compressed under exterme pressure yield a panel density of above 800kg/m3 greatly superseding standard IS requirements and making it highly densified & homogenous. IT is Inherently Borer and termite resistant, displays anti warp features and has extreme hardness and strength..

Technical Specifications


Properties Specifications
Strength grade HS Strength class D50
Bending parallel to grain 16.0 N/mm2
Tension parallel to grain 9.6 N/mm2
Compression parallel to grain 15.2 N/mm2
Compression perpendicular to grain 4.5/3.5 N/mm2
Shear parallel to grain 2.20 N/mm2
Modulus of elasticity mean 15000 N/mm2
Modulus of elasticity minimum 12600 N/mm2
Characteristic density 650 kg/m3
Average density 7800 kg/m3
Strength class for joint design D50
Compared to teak as 100
Weight 105
Retention of shape 50
Shear 105
Hardness 95
Nail / screw holding power 100

PLYINTERNAT

PlyInternat, is our superior brand which is also rated high for its endurance, tooling and finishing capabilities. Our meticulous Research & Development Dept. over the years has led us to create a wide range of premium products which are tropicalised, termite & borer proof, as well as water proof and anti wrap.
